pocket size mini wireless thermal printer
3. Product Features
1.Overall the scheme of low power consumption has strong life;
2.High capacity rechargeable lithium ion batteries, increased the working time for the printer;
3.The high performance printer machine, greatly enhance the printing effect and service life;
4.High speed processor, the machine response more quickly;
5.Low power consumption of the bluetooth module,Support the Android and system;
6.Simple and practical, carton design can be convenient and quick to replace printing paper;
7.Compatible with ESC/POS command set;
8.Power supply, power, lack of paper, charging indication function, provides the user with more intuitive state information;
9.Easy to operate,Small and beautiful;
4.Specification
|
Printing way |
Bluetooth printer |
|
Effective print paper width |
48mm |
|
Printing paper |
57.5±0.5mm |
|
Printer core life |
50KM(25% print density or less)100million puises) |
|
Printing speed |
80 mm/s |
|
Printing content |
Support any language |
|
Outer dimension |
102 x 76.5 x 40mm |
|
Weight |
183g(Contains battery without paper) |
|
Rolling paper Diameter |
≤30.5mm |
|
Interface |
USB and Bluetooth2.1 |
|
Environment parameters |
Working temperature: -10°C~ 50°C Working humidity: 20% ~ 85% Storing temperature : -20°C ~ 70°C Storing humidity: 5% ~ 95% |
|
Paper feeding method |
Easy paper loading |
|
Power supply |
7.4V, two 1400mAH lion battery pack |
|
Printers core life |
50km (25% print density or less) |
|
Charging Interface |
DC12V, 1A |
|
Charging time |
About 2 hours; the charging and full indication |
|
Instruction Set |
ESC / POS compatible instruction set |
|
Shutdown Current |
<1uA |
|
Standby Current |
10mA |
|
Standby time |
150h |
|
Print average current |
1.5A |
|
Print Length |
Greater than 200m (12.5% print density) |
